Forge blow off valve mounting kit Mini R58/60 after 2011 - Peugeot 208 after 2012

Designed specifically for Peugeot/BMW N18 engines, (Cooper S from 2011, JCW Cooper S from 2013, R58 Coupe from 2012, Peugeot 208 GTi from 2012, Peugeot 308 GTI, RCZ THP 156 & 200 2011 on).
This product is recommended when the turbo pressure has been increased by reprogramming, for those who want to have a big dump valve noise, or simply for more reliability compared to the fragile original components. The main known problem on the stock valve is a tear on the diaphragm that prevents the valve from opening fully. This does not always trigger the engine light to come on because the valve can be opened by turbo pressure. This is a very common problem. The other problem is that the stock spring cover is made of very thin plastic and becomes brittle with time, heat and oil, and eventually fails.
This prevents the diaphragm from sealing and also causes the problems outlined above. This failure can also cause the dump valve to break when the turbo is removed, and in rarer cases plastic components enter the turbo and destroy it.

The alternative Forge offers significantly increases reliability. Their valve is made entirely of aluminum and works with a piston (which does not break unlike the diaphragm), it replaces the original component with a pressure/vacuum operated piston that also retains the control of the stock ECU on the valve. This dump valve has been tested on VAG vehicles for many years. The spring is interchangeable for different turbo pressure levels, and the solenoid plugs directly into the included harness connector. To be sure you are purchasing the right dump valve for your vehicle, you can refer to the compatibility list below before ordering.

Compatible component

FM207V Dump valve for N14 Cooper S 2007-10, JCW Cooper S 2007-2012 engines
FMDVR60R Closed loop dump valve for N18 Cooper S engines from 2011, JCW Cooper S from 2013
FMDVMCS Adapter plate for open circuit dump valve Cooper S Turbo 2007-2008 only
FMDVR56A Dump valve open circuit for N14 Cooper S 2007-10, JCW Cooper S 2007-2012 engines
FMDVR60A Dump valve open circuit for N18 Cooper S engines from 2011, JCW Cooper S from 2013

In the box:

1 x FMDVR60A Valve
1 x Harness connector
1 x Solenoid, bracket and screw
1 x 2000mm vacuum hose 4mm
1 x Aluminum spacer
1 x M6 x 30 Allen Screw
1 x M6 Clamping washer
1 x M6 Nyloc nut
1 x Red reinforced spring
10 x Cable clamp
1 x 5mm T-connector
1 x Forge and Sticker key ring.

This product is only available with a polished alloy finish.
