ACL connecting rod bushes for FORD Focus RS/ST and VOLVO B5202/4, B5234/T, B5244/T, B5254/T
ACL Trimetal bushes (hardened steel + copper + nickel) are designed for racing use. They reduce friction, improve operating temperatures and optimise oiling.
Model 5B7880H-STD is specially designed for FORD and VOLVO engines, offering perfect tolerance for precise connecting rod adjustment.
These bearings are offered in STD rib and also in repair rib.
Specifications :
Part number: ACL-5B7880H-STD
Tolerance: Standard size (STD)
Material: Tri-metal alloy (copper, lead, tin)
Recommended use: Motorsport, competition, engine preparation
Advantages : Increased abrasion resistance, optimum heat dissipation, precise fit
Dimensions:
Maximum overall length: 19.50 mm
Minimum axle size: 49.984 mm
Maximum axle size: 50 mm
Minimum tunnel size: 53 mm
Maximum tunnel size: 53.013 mm
Max wall to crown: 1,496 mm
Minimum vertical oil clearance:
Max vertical oil clearance:
Compatibility :
FORD : Focus RS / ST 2.5L 5 Cyl Turbo (HUBA ,HUWA, HYDA, HYDB, HYDC, JZDA)
VOLVO : B5202, B5204, B5234/T, B5244/T, B5254/T - 5 Cyl 2.0L,2.3L,2.4L,2.5L inc Turbo
Each set of pads is sold sealed by the manufacturer to guarantee the protection, quality, and authenticity of the product. It is essential to check the references and dimensions before opening.
In order to maintain optimal reliability for all our customers, returns are only possible for products whose plastic packaging has not been opened.
