AP Racing 4 pistons brake caliper 25.4mm LHT CP334 Front Left
Reference:
AP-CP5040-11S4
Supplier Ref.:
CP5040-11S4
The AP Racing CP5040 4-piston disc brake caliper is designed for use in competition and offers reliable, high-performance braking on the track. Part of the Pro 5000 range, it benefits from AP Racing's experience in motorsport.
Its radial mounting ensures excellent rigidity and rapid braking response, providing good pedal feel. This front left caliper is compatible with Ø280 or Ø295 mm discs (25.4 mm thick) and features four Ø38.1 mm pistons, which guarantee powerful and well-modulated braking.
Specifications:
- Piston diameter (mm): Ø38.1 × 4
- Total piston surface area: 45.6 cm²
- Weight (without pads): 1.9 kg
- Hydraulic thread: M10 × 1.0
- Mounting type: radial
- Mounting centre distance (mm): 130.0
- Mounting offset (mm): 43.2
- Mounting hole diameter (mm): 10.2
- ‘PL’ dimension (mm): 53.0
- Bleeding screw tightening torque: 17 N·m
- Position: Front
- Side: Left
Details Brake pad:
Pad reference: CP3345D44
Friction surface: 43.4 cm²
Pad depth: 44.1 mm
Thickness: 16.0 mm
Spare parts – Caliper
Pistons:
— Aluminium: CP3215-113
— Stainless steel: CP5560-110
Seal repair kit: CP4518-JJ
Stainless steel piston kit: CP5040-42
Pad retention:
—Retaining screw: CP5100-116 × 1
—Retaining bolt: CP5100-125
Wear plates (Wear Plates)
— CP5100-210 × 2
— CP5100-211 × 2
Piston knock-back prevention spring kit: CP6518-4LBLL
Bleed screw: CP3720-173
Hydraulic connection/header us manifold: CP5000-54
Disc details:
— Ø295 × 25.4 mm: CP5000-510 / CP5000-511CG8
Products intended for vehicle modification for competition purposes may render their use prohibited on public roads, insofar as they significantly alter the vehicle's characteristics as specified in the type-approval certificate issued by the relevant authorities (noise level, pollutant emissions, maximum speed, tire dimensions, etc.).
