ARP Connecting Rod Screw Kit for Peugeot, Citroën TU, and Volkswagen G60

The ARP connecting rod screw kit is designed for the original connecting rods of Peugeot Citroën TU2, TU3, and TU5* engines, as well as the Volkswagen Golf GTI 1.6 and Corrado G60. Designed to exceed the requirements of the original mounting components, these connecting rod screws offer high mechanical strength and excellent fatigue resistance for both series engines and high-performance builds.

Manufactured from 8740 chromium-molybdenum steel, they are part of the ARP High Performance range and feature a tensile resistance of 180,000 psi, or approximately 1,241 MPa. Their manufacturing process includes heat treatment followed by grinding and thread rolling to enhance fatigue resistance and ensure reliable, long-lasting tightening under demanding operating conditions.

Technical Specifications

• Brand: ARP
• Manufacturer Part Number: 104-6002
• Type: connecting rod screw kit
• Range: High Performance Series
• Compatibleconnecting rods: original equipment connecting rods only
• Mounting: through-bolts with nuts
• ARP head type: K
• Nut type: 12-point
• Socket size: 11 mm
• Material: 8740 chromium-molybdenum steel
• Resistance to traction: 180,000 psi, or approximately 1,241 MPa
• Nuts included: yes
• Packaging: set of 8 bolts

Compatible engine types

• Peugeot Citroën TU2*: TU24 and TU2J2.
• Peugeot Citroën TU3*: TU3J2.
• Peugeot Citroën TU5*: TU5J4, TU5JP4, and TU5JP4S.
• Volkswagen Golf GTI 1.6: EG 1.6 8V water-cooled engine.
• Volkswagen Corrado G60: 1.8 supercharged engine.

TU* applications include, in particular , the Peugeot 106 Rallye, XSi, and S16; 205 Rallye; 206 XS 16V; as well as the Citroën AX Sport, GT, and GTi; Saxo VTS; and C2 VTS, depending on their engine configuration and connecting rod mounting.

Mounting for original connecting rods and adaptation for TU* engines

This kit is intended solely for compatible original connecting rods. It should not be considered a universal fastener kit for forged connecting rods or replacement connecting rods.

* On TU engines, a slight modification to the bolt head is required. The round head must be given a flat spot by lightly grinding a small area to allow it to rest against the connecting rod stop and prevent the bolt from rotating while tightening the nut.

This simple modification will preserve the contact patch beneath the head and the transition spoke between the head and the bolt shank. Then, check the positioning and rotational lock of each bolt before assembly.

Follow the ARP tightening specifications applicable to part number 104-6002. ARP also requires that the connecting rod top end bore be re-machined to specification after installing the new bolts.

Key Features

• High-resistance 8740 steel.
• Resistance to traction of 180,000 psi.
• Threads rolled after heat treatment to enhance fatigue resistance.
• Includes 12-point nuts with a 11 mm socket size.
• Set of 8 bolts for four compatible OEM connecting rods.
