VDO Cooling Fluid Temperature Sensor, +40 to 120 °C, M16×150, with 110 °C Alert
The VDO cooling fluid temperature sensor with an M16×150 connection is used to measure cooling fluid temperature. It operates in the range of +40 to 120 °C and outputs a resistive signal intended for a compatible temperature indicator.
The outlet range of 287.4 to 22.7 ? must match the electrical specifications of the gauge or indicator being used. An identical display range alone is not sufficient to guarantee compatibility. The 110 °C ± 3 °C contact provides a separate function from the measurement, designed to control a compatible warning light.
Technical Specifications
- Brand: VDO
- Manufacturer Part Number: 323-803-001-007D
- Type: Cooling fluid temperature sensor
- Measurement range: +40 to 120 °C
- Thread: M16×150
- Resistive signal: 287.4 to 22.7 ?
- Operating voltage: 6 to 24 V DC
- Contact d’alerte: 110 °C ± 3 °C
- Type of grounding: Grounded through the probe body
- Measurement connection: 6.3 x 0.8 mm flat plug
- Alarm contact connection: 6.3 x 0.8 mm flat plug
Compatibility and Mounting
Check the M16×150 thread, the resistance curve, and the connection before mounting. The probe body must maintain electrical continuity with the circuit ground.
-
Sensor typeWater Temperature
