The Stack ST537 red indicator is designed for flush mounting on the dashboard. It provides a visual alert for warnings transmitted by the instrumentation to which it is connected.
Its flange, with an outside diameter of 14.7 mm, and its projection of only 9.1 mm above the panel make it easy to install in tight spaces. It is suitable for 12 V and 16 V electric power systems, with a consumption of 100 mA when illuminated.
Technical Specifications
- Brand: Stack
- Manufacturer Part Number: ST537
- Type: recessed warning indicator
- Indicator color: red
- Outside diameter of the flange: 14.7 mm
- Projection above mounting surface: 9.1 mm
- Recommended maximum panel thickness: 9.6 mm
- Minimum clearance required behind the panel: 50 mm for wiring and installation
- Power supply: 12 V and 16 V systems
- Consumption when on: 100 mA
Mounting and Wiring
Install the indicator on a panel with a maximum recommended thickness of 9.6 mm. Allow at least 50 mm of clearance behind the panel to accommodate wiring and connections.
The outer diameter of the flange does not match the bolt hole diameter. Verify the mounting sizes and electrical compatibility with the instrumentation being used before installation.
Key Features
- Red indicator light for displaying an alert on the dashboard.
- Compact flush-mount mounting design with a 9.1 mm protrusion.
- Compatible with 12 V and 16 V systems.
- Consumption of 100 mA when illuminated.
